Microscope FX604 - 16MP Camera, HDMI
Microscope FX604 - 16MP Camera, HDMI
Microscope FX604 - 16MP Camera, HDMI
Microscope FX604 - 16MP Camera, HDMI
Microscope FX604 - 16MP Camera, HDMI
Microscope FX604 - 16MP Camera, HDMI

Microscope FX604 - 16MP Camera, HDMI

352.90 € with VAT
291.65 € without/VAT
For orders above 1,000 € you get FREE shipping

Camera/microscope FX604 designed for service work: repair of the motherboard by soldering. Camera: 16MP, HDMI. Package includes: microscope, camera, pad, cover, LED light, lens and UV glass.

Manufacturer
FX

Match code

NAR-MSC-002

Artikel

1100215295

Add to wishlist

FX604 microscope with 16 MP camera, HDMI

  • service tool: mobile phone motherboard repair by soldering
  • HDMI camera adapter: 16MP 1400W 60FPS, 1 / 2.3 inches

Features:

  • 7X-45X Extremely large zoom
  • Trinocular design for high quality display, USB PC and CCD Video Imaging
  • stereo sharp images in the SUPER field of view
  • Precise alignment for long-term, fatigue-free tracking
  • Crystal clear original images in true colors
  • 45 Inclined trinocular head
  • 30 mm SUPER wide-angle eyepieces
  • Both eye tubes with adjustable diopter
  • Adjustable interpupillary distance
  • Complete optical glass elements
  • Precision cut glass lenses
  • 4 "(100 mm) extremely long working distance
  • Versatile boom stand covering a large work surface
  • Two-arm design for 3-degree freedom
  • Able to position the microscope head in any direction
  • Durable cast steel stand with enamel finish: stain resistant
  • Robust solid steel base
  • Auxiliary lens with a working distance of 165 mm and 30 mm

Technical specifications:

  • Head: 45 tilted 360 rotating trinocular head with simultaneous focusing
  • Eyepiece: 30 mm super wide-angle high-eyepoint WF10X / 20 mm
  • Target: 0.35-9.0X
  • Auxiliary lens (optional): SZM 0.5X & SZM 2.0X
  • Zoom range: 6.4: 1
  • Dioptric correction: 5dp
  • Interpupillary distance: 2-3 / 16 "- 2-15 / 16" (55-75 mm)
  • Field of view: 2-1 / 2 "(65 mm) in diameter
  • Working distance: 4 "(100 mm)
  • Boom stand: 20 "double arm (total length: 30"), 17 "high column, 10-1 / 4" x8-1 / 4 "x2-0" solid steel base

package contents:

  • 1x 7-45X trinocular stereomicroscope
  • 1x 380MM * 250MM aluminum alloy pad (fixed microscope base)
  • 1x 16 MP HDMI camera
  • 1x Dust cover
  • 1x LED light
  • 1x lens
  • 1x UV glass

Specification

  • Tool type
    Tools
  • Category
    Microscopes & Cams
  • Netto weight (kg)
    0.000
  • Ean
    2200000403872
