Relife M-16 - Trinocular Microscope Camera 4K, HDMI

Relife M-16 - Trinocular Microscope Camera 4K, HDMI

The Relife M-16 is a high-definition trinocular microscope camera that offers unparalleled clarity with its 4K resolution and HDMI connectivity. Designed for precision and ease of use, it is perfect for a wide range of applications, including electronics repair, laboratory research, and industrial inspection. Its advanced features and robust construction make it a valuable tool for professionals requiring detailed visual analysis.

Features:

• High-Definition Sony Chip: Equipped with a 1/2-inch Sony chip, it delivers high sensitivity and rich picture effects.
• 4K Image Quality: Provides 30 frames per second image output with a resolution of 3840*2160, ensuring clear and detailed visuals.
• Versatile Connectivity: Supports HDMI, USB-PC, and U-disk photo and video interfaces for flexible usage options.
• User-Friendly Interface: Features a clear interface and easy operation, with real-time output connected to an HDMI display.
• Integrated Measurement System: Comes with a built-in measurement system for real-time measurement, photographing, and video recording.

Technical Parameters:

• Sensor: 1/2 inch Sony chip.
• Resolution: 4K (3840*2160) at 30fps; 1080p at 60fps.
• Net Weight: About 205g.
• Product Size: 66 x 66 x 40mm.
• Package Size: 15083160mm.
• Video Output: HDMI/USB-PC/U disk photo and video interface.
• Camera Interface: CS.
• Operating Voltage: 12V.
• Working Current: 200mA.
• Photosensitive Size: 1/2 inch.
• Cell Size: 2μm*2μm.
• Effective Pixels: 4K (3840*2160).
• Clarity: 2000 TVline.
• Frame Rate: 4K at 30fps; 1080p at 60fps.
• Dynamic Range: 78dB.
• Signal To Noise Ratio: 40dB.
• Menu Language: English/Chinese.
• White Balance Mode: One-touch white balance/Manual/Auto.
• Crosshair: Supports 10 horizontal and vertical lines, color/line width adjustable.
